Description
Specifications:
– Model: TG-VM1540D+ (VM1540D Plus)
– Size: 15″
– Impedance: Usually D2 = 1Ω final parallel / 4Ω series. If D4 = 2Ω final parallel / 8Ω series
– RMS: 2000W-2500W RMS
– MAX: 15000W MAX (marketing)
– Fs: ∼34-39Hz
– Sensitivity: ∼90dB
– Power: 2000W-2500W RMS TRUE (box says 7500W-15000W MAX) / Daily 2000W clean, burp 4000W+
– Coil: 3″ (76mm) high-temp flat copper 4-layer on black aluminum former, Dual 2-Ohm D2 (2Ω+2Ω = 1Ω parallel) – some batches D4 (4+4 = 2Ω parallel) check sticker
– Motor: Triple stack ∼180-200oz, vented T-yoke, push terminals
– Cone: Reinforced black non-pressed paper + carbon, tall high-roll foam surround double-stitched, big vented aluminum dustcap with Venom logo
– Basket: Heavy cast aluminum 15″ basket, silver/black
– Suspension: Double / Triple Nomex spiders with sewn direct leads
