Targa tgczbr121b 12” Subwoofer

Description

Specifications;
Model TG-CZ-BR-121D / CZ-BR-12D4
Series CZ Bass Reflex Series
Size 12″ / 300mm
Type Subwoofer DVC – Ported Only
Power MAX 10000W MAX (Marketing)
Power RMS 1200W – 1500W RMS TRUE Daily
Impedance Dual 4-Ohm DVC (4Ω + 4Ω)
Final Wiring Single 2Ω Parallel (loud) / 8Ω Series
Final Wiring Pair 1Ω All Parallel (loudest) / 4Ω Series-Parallel
Voice Coil 2.75″ – 3.0″ / 70-76mm Flat Copper, 4-Layer, Aluminum Former
Magnet Triple Stack Ferrite, 140-160oz / 40-45mm
Basket Cast Aluminum, 6-Spoke Heavy Duty
Cone Red/Black Reinforced Non-Pressed Paper
Surround High-Roll Foam, Double Stitched to Cone
Dustcap Vented Aluminum with CZ Logo
Spider Double Nomex Progressive with Sewn Direct Leads
Fs 32Hz – 38Hz
Sensitivity 88dB – 90dB
