Description
Specifications:
– Model: TG-CZ151D / TG-CZ154D also exists (Dual 4 version)
– Size: 15″ / 380mm
– Impedance: Dual 1-Ohm (1Ω+1Ω)
– Wiring: Single = 0.5Ω parallel / 2Ω series. Pair = 1Ω final (series-parallel)
– RMS: 1500W-2000W RMS daily (3000W burp capable)
– MAX: 20000W MAX dynamic
– Fs: ∼28-32Hz
– Sensitivity: ∼88-89dB
– Power: 1500W-2000W RMS TRUE (older batch labeled 1500W RMS, newer 2000W RMS) / 20000W MAX
– Voice Coil: 3″ (76mm) high-temp copper 4-layer on black aluminum former, Dual 1-Ohm
– Motor: 180oz-200oz triple-stack ferrite motor, fully vented T-yoke, massive cooling
– Cone: Reinforced non-pressed paper with DDC treatment, high-roll foam surround double-stitched, progressive Nomex spider with direct tinsel leads
– Basket: Full cast aluminum 15″ basket – no flex even at full excursion
– Terminals: Heavy-duty 8AWG push / screw combo
