Description
Specifications:
– Model: TG-C1043B
– Size: 10″ / 250mm
– Impedance: Usually D2 = 1Ω parallel / 4Ω series. If D4 = 2Ω parallel / 8Ω series. Check sticker.
– RMS: 1500W-2000W RMS daily (3000W burp)
– MAX: 6000W
– Fs: ∼38-45Hz
– Sensitivity: ∼88-89dB
– Power: 1500W-2000W RMS TRUE (box says 3000W-6000W MAX, but real daily 1500W) / 6000W MAX dynamic
– Coil: 3″ (76mm) copper 4-layer, Dual 2-Ohm most B batches (2Ω+2Ω = 1Ω final) – some D4 exist
– Motor: Triple/Quad stack ∼150-180oz, vented T-yoke
– Cone: Black reinforced paper cone, high-roll foam surround triple-stitched, aluminum dustcap
– Basket: Full cast aluminum 10″ basket – zero flex
– Suspension: Dual Nomex spiders with direct leads
