Description
Specifications:
– Model: TG-CR154D
– Size: 15″ / 380mm
– Impedance: Dual 4-Ohm DVC
– Wiring: Single sub = 2Ω parallel (loud) / 8Ω series (quiet). Two subs = 1Ω final (all parallel) – BEST for 1-Ohm amp
– RMS: 800W RMS
– MAX: 10000W MAX
– Fs: ∼28-32Hz
– Sensitivity: ∼88dB
– Power: 800W RMS TRUE (some old boxes say 650W, new batch 800W) / 10000W-11000W MAX
– Voice Coil: 2″ copper, Dual 4-Ohm (4Ω+4Ω)
– Motor: ∼70-80oz single/double stack, vented pole
– Cone: Non-pressed paper cone, foam surround stitched, stamped steel black basket
– Spider: Single progressive spider with tinsel leads
