Description
Specifications:
– Model: TG-C1543B
– Size: 15″ / 380mm
– Impedance: Usually D2 (2Ω+2Ω) = 1Ω parallel / 4Ω series. If D4 (4Ω+4Ω) = 2Ω parallel / 8Ω series – look at magnet sticker.
– RMS: 2500W-3000W RMS daily (5000W burp in correct box)
– MAX: 10000W-12000W
– Fs: ∼35-40Hz
– Sensitivity: ∼90.6dB
– Power: 2500W-3000W RMS TRUE (box says 6000W RMS MAX, but real clean daily is 2500W) / 10000W-12000W MAX dynamic
– Voice Coil: 3.5″ (89mm) high-temp copper 4-layer on aluminum former, Dual 2-Ohm (most B models) – some Dual 4-Ohm batches exist – check your terminals
– Motor: Quad-stack ∼220-250oz ferrite, massive vented T-yoke + cooling, 10″ spider plateau
– Cone: Reinforced non-pressed black paper / carbon fiber composite cone, 3x stitched high-roll foam surround, aluminum dustcap with Targa logo
– Basket: Full 15″ heavy cast aluminum, 12-spoke, non-flex
– Suspension: Triple Nomex progressive spiders with bolted direct leads
